TP-LINK VIGI NVR1004H 4P 4 CHANNEL POE NETWORK VIDEO RECORDER

NETWORK Protocol TCP/IP, DHCP, DNS, NTP, UPnP Incoming Bandwith 80 Mbps Outgoing Bandwidth 60 Mbps GENERAL Operating Temperature -10–55 °C Package Contents VIGI Network Video Recorder Power Adapter HDD Screws Quick Installation Guide Dimensions( W X D X H ) 246.2 × 148.2 × 45 mm PoE Standard: 802.3af/at PoE Ports: Ports 1-4 PoE Budget: 53 W External Power Supply 53.5V DC/1.31A Power Consumption 4.25 W (without disk) INTERFACES Network Interface 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface USB Interface 2× USB 2.0 HARD DISK SATA 1 SATA Interface Capacity Up to 10 TB VIDEO/IMAGE Video Input 4-Channel IP Video Input, up to 8MP Resolution Recording Resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/ DCIF/2CIF/CIF/QCIF HDMI Output Resolution 1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz VGA Output Resolution 1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz DECODING Decoding Format H.265+/H.265/ H.264+/H.264 Live View/Playback Resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/ DCIF/2CIF/CIF/QCIF Synchronous Playback 4 Channel Capability 2-ch @ 8MP, 4-ch @ 4MP
